Linear Open Systems
Open systems provide a cost-optimized solution for engineers seeking to integrate a resistive element into their designs.
LFP Series
(Linear foil potentiometer)
Potentiometric resistive elements with foil collector and mechanical pressure pin, hermetically bonded.
MANUALS
CAD
CONTACT
Only available in quantities >200 pcs.
| Stroke Length | Linearity | Life (mech.) | Sealing | Outputs | Data Sheet | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
50 mm |
≤ ±0.4 % |
25 million movements |
IP67 |
0 to voltage supplied |
  |
|
|
|
|
|
|
|
|
|
|
100 mm |
≤ ±0.4 % |
25 million movements |
IP67 |
0 to voltage supplied |
  |
|
|
|
|
|
|
|
|
|
|
150 mm |
≤ ±0.4 % |
25 million movements |
IP67 |
0 to voltage supplied |
  |
|
|
|
|
|
|
|
|
|
|
200 mm |
≤ ±0.4 % |
25 million movements |
IP67 |
0 to voltage supplied |
  |
|
|
|
|
|
|
|
|
|
|
250 mm |
≤ ±0.4 % |
25 million movements |
IP67 |
0 to voltage supplied |
  |
|
|
|
|
|
|
|
|
|
|
300 mm |
≤ ±0.3 % |
25 million movements |
IP67 |
0 to voltage supplied |
  |
|
|
|
|
|
|
|
|
|
|
350 mm |
≤ ±0.3 % |
25 million movements |
IP67 |
0 to voltage supplied |
  |
|
|
|
|
|
|
|
|
|
|
400 mm |
≤ ±0.3 % |
25 million movements |
IP67 |
0 to voltage supplied |
  |
|
|
|
|
|
|
|
|
|
|
450 mm |
≤ ±0.3 % |
25 million movements |
IP67 |
0 to voltage supplied |
  |
|
|
|
|
|
|
|
|
|
|
500 mm |
≤ ±0.3 % |
25 million movements |
IP67 |
0 to voltage supplied |
  |
|
|
|
|
|
|
|
|
|
PTP Series
Position transducer in open housing.
MANUALS
CAD
CONTACT
| Stroke Length | Linearity | Life (mech.) | Sealing | Outputs | Data Sheet | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
10 mm |
≤ ±0.25 % |
50 million movements |
- |
0 to voltage supplied |
  |
|
|
|
|
|
|
|
|
|
|
25 mm |
≤ ±0.20 % |
50 million movements |
- |
0 to voltage supplied |
  |
|
|
|
|
|
|
|
|
|
|
50 mm |
≤ ±0.10 % |
50 million movements |
- |
0 to voltage supplied |
  |
|
|
|
|
|
|
|
|
|
|
75 mm |
≤ ±0.10 % |
50 million movements |
- |
0 to voltage supplied |
  |
|
|
|
|
|
|
|
|
|
|
100 mm |
≤ ±0.10 % |
50 million movements |
- |
0 to voltage supplied |
  |
|
|
|
|
|
|
|
|
|
|
125 mm |
≤ ±0.05 % |
50 million movements |
- |
0 to voltage supplied |
  |
|
|
|
|
|
|
|
|
|
|
150 mm |
≤ ±0.05 % |
50 million movements |
- |
0 to voltage supplied |
  |
|
|
|
|
|
|
|
|
|
|
175 mm |
≤ ±0.05 % |
50 million movements |
- |
0 to voltage supplied |
  |
|
|
|
|
|
|
|
|
|
|
200 mm |
≤ ±0.05 % |
50 million movements |
- |
0 to voltage supplied |
  |
|
|
|
|
|
|
|
|
|
|
250 mm |
≤ ±0.05 % |
50 million movements |
- |
0 to voltage supplied |
  |
|
|
|
|
|
|
|
|
|
|
300 mm |
≤ ±0.05 % |
50 million movements |
- |
0 to voltage supplied |
  |
|
|
|
|
|
|
|
|
|
PTN Series
Resistive elements and wiper with laser linearization for mounting in closed devices.
MANUALS
CAD
CONTACT
| Stroke Length | Linearity | Life (mech.) | Sealing | Outputs | Data Sheet | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
25 mm |
≤ ±0.25 % |
50 million movements |
- |
0 to voltage supplied |
  |
|
|
|
|
|
|
|
|
|
|
50 mm |
≤ ±0.25 % |
50 million movements |
- |
0 to voltage supplied |
  |
|
|
|
|
|
|
|
|
|
|
75 mm |
≤ ±0.10 % |
50 million movements |
- |
0 to voltage supplied |
  |
|
|
|
|
|
|
|
|
|
|
100 mm |
≤ ±0.10 % |
50 million movements |
- |
0 to voltage supplied |
  |
|
|
|
|
|
|
|
|
|
|
150 mm |
≤ ±0.10 % |
50 million movements |
- |
0 to voltage supplied |
  |
|
|
|
|
|
|
|
|
|
|
200 mm |
≤ ±0.10 % |
50 million movements |
- |
0 to voltage supplied |
  |
|
|
|
|
|
|
|
|
|
|
250 mm |
≤ ±0.10 % |
50 million movements |
- |
0 to voltage supplied |
  |
|
|
|
|
|
|
|
|
|
