Application Selector Guide
CALL 1-800-667-7492
Click on a sensor

Application Selector Guide

Table can be scrolled left/right on mobile

INDUSTRY APPLICATION Linear sensors Rotary sensors N= Non-Contact
P= Potentiometric
T= Touchless
Aerospace Rudder, Ailerons Position Vert-X 22 N
Seat Position Adjustment ML
Agricultural Machines Tractors, Hoe Position Feedback LWG, LWX, TH1 P, T
Tractors, Steering Sensor LWX, TH1 Vert-X 37, RSC2800 P, N, T
Alternative Energy Windmills, Blade Control TH1, TP1 P2500, RSC2800 T, P
Wood Gasification TH1, TP1 T
Solar Tracker Position Feedback LWX, TH1 Vert-X 22E, RFC4800 T
Automotive Motorcycle Throttle Position SP2800, RSC2800 P, N, T
Bio-Pharma Pill Testing P2200, P4500, P6500 P
Blood Separation GL200 P
Factory Automation Feedback Device for Motion Control T, TR, LWH, TLH, LWG P2200, P4500, P6500, RSC2800, Vert-X2200 N, P
Dimensional Quality Control of Parts T, TS, TR, TRS P
Thickness Control on Strip Material T, TS, TR, TRS
Dancer Arm Measurement P2200, SP2800, Vert-X 1300, Vert-X2200 P, N
HVAC Valve Position Feedback LWG PL240, PL300, SP2800, RSC2800 P
Material Handling Forklift Steering Feedback SP2800, RSC2800 P, N
Forklift Tilt Angle Feedback TEX P
Electro-Hydraulic Lifting Tools & Handling TLH, LWH P
Medical Equipment X-Ray Machine aperture blade Positioning T, KL P
Respiratory Flow Valve Control T, TS P
Oncology Machine treatment focus P4500 P
Oil & Gas Oil Wells, Feedback Device for Hydraulic Drives LWX P6500, IP6000, IPS6000 P
Mobile Electronics Human Transporter Steering Sensor SP2800 P
Fastbrake Handle Sensor for Locomotives SP2800, RSC2800 P, N
Control Head Sensor for Boats PL300 P
Trim Sender Sensor for Boats PD280 P
Railroad Measurements FTI, LWX P
Boom Angle Measurement on Cranes P2200 P
Beach-cleaning Vehicle, Pick-up Roller LWX P
Plastics Manufacturing Position Feedback on Injection Molding Machines LWH, TLH, TP1, TH1 IP6000 P
Blow Molding Machines TP1, TLH T
Power Generation High Voltage Switches, Position Control LWH, TLH P
Process Control Valve Position Control TLH, TH1, LWH, TEX, PTP SP28, RSC28 N, P, T
Level Sensing TH1 Vert-X -13E series, Vert-X -22E series, Vert-X -37E series T
Robotics Manipulator Arm Position Controls TH1 Vert-X -13E series, Vert-X -22E series, Vert-X -37E series, Vert-X 5100 T, N
Theme Park Rides Cartoon Character Animation Control TEX Vert-X2200 N
London Eye, Position Sensing Loading Ramp LWG, LWX P
Tools/Machinery Molding Press Position Feedback LWH, TLH, LWG, TP1 P, T
Saw, Blade Position Feedback TH1 T
Sheet Metal Forming TP1 T
Packaging Machines TP1, LWH, TLH P, T
Concrete Construction Machines TP1 T
Stone Cutting and Forming Machines TP1, LWH, TLH P, T
Printing Machines, Flying Splicer for Paper TLH, LWH P
Ironing Machine Linear Undercarriage Mov. T, TS, TR, TRS P
Screen Printing, Distance Screen to Table T, TS, TR, TRS P
Dosing Machines T, TS, TR, TRS P
Wear Testing Machines LWG, LWH P, T
Crash Test, Deformation Measurement LWH, LWG, TP1 P, T
Vehicle Test Equipment, Shaker Test TP1, TH1 P, T
