TP1 Series Wear-Free Linear Position Sensor That's A Snap To Design-In
Stroke Length Linearity Outputs

50 to 4,250 mm

≤ ±0.02 %

0.1 to 10 VDC, -10 to +10 VDC, 0.1 to 20 mA, 4 to 20 mA

50 to 4,250 mm

< ±50 μm up to 1,000 mm
< ±80 μm up to 2,500 mm
< ±120 μm up to 4,250 mm

Start-Stop-Pulse

50 to 4,250 mm

< ±25 μm up to 250 mm
< ±30 μm up to 750 mm
< ±50 μm up to 1,000 mm
< ±80 μm up to 2,500 mm
< ±120 μm up to 4,250 mm

SSI

50 to 4,250 mm

< ±25 μm up to 250 mm
< ±30 μm up to 750 mm
< ±50 μm up to 1,000 mm
< ±80 μm up to 2,500 mm
< ±120 μm up to 4,250 mm

CANopen

50 to 4,250 mm

< ±25 μm up to 250 mm
< ±30 μm up to 750 mm
< ±50 μm up to 1,000 mm
< ±80 μm up to 2,500 mm
< ±120 μm up to 4,250 mm

Incremental Quadrature

50 to 4,250 mm

< ±25 μm up to 250 mm
< ±30 μm up to 750 mm
< ±50 μm up to 1,000 mm
< ±80 μm up to 2,500 mm
< ±120 μm up to 4,250 mm

IO-Link


Every one of Novotechnik’s TP1 Series of magnetostrictive position sensors come with one vital thing that’s not in the specs and is equally important – unmatched technical support.

Our engineers work with you before you even decide to select our part to discuss your application and answer your questions. If you choose the TP1 Series, we’ll support you in three ways:

1) work with you through your design process to help you make the best choice for your application and get predictable results

2) help you get the most from our TP1 Series to meet your applications requirements

3) continued support, should you need it, even after the sale and your production starts

Novotechnik's TP1 Series of magnetostrictive position sensors provide unlimited mechanical life, high accuracy and are easy to design-in to your application. Output interfaces include analog with programmable end-points, start/stop, SSI, and quadrature.

  • Magnetostrictive touchless technology
  • Stroke lengths from 50 to 4500 mm
  • Outstanding linearity: to 10 micrometers
  • Resolution to 0.001 mm regardless of stroke length
  • No reference start position needed
  • Programmable end points on analog mode
  • No velocity or acceleration limits for position markers
  • Low temperature coefficient to 15 ppm
  • Analog, Quadrature, Start/Stop, SSI and DyMoS interfaces
  • Cable or connector versions
  • Protection class to IP 68 Unlimited mechanical life
