Rotary Position Sensors

RSC3200 Series

  • Shaft connectivity options
  • Built-in coupling accepts D-shaft or custom options
  • Non-contacting, magnetic measuring principle (Hall effect)
  • Redundant system
  • Measuring range up to 360°
  • Temperature range -40° up to +125°C
  • Easy mounting
  • Protection classs IP69K
  • Long life
  • Good price/performance ratio

RSC6600 Series

  • Non-contacting, magnetic
  • Measuring range up to 360°
  • High temperature range
  • Easy mounting
  • Protection class up to IP 67 (mounted with o-ring)
  • Long life
  • Good price/performance ratio

RSC2800 Series

  • Non-contacting, magnetic
  • Electrical range 30° up to 360° in 10°-steps available
  • Available with push-on coupling or marked shaft
  • Simple mounting
  • Protection class IP54 or IP65
  • Long life
  • Internal resolution 12 Bit
  • Independent linearity ±0.5 %
  • Redundant output signal

SP5000 Series

  • Easy mounting
  • Protection class up to IP 67 (mounted with o-ring), IP 40 shaft side
  • Long life
  • Good price/performance ratio

SP1600 Series

  • Easy mounting
  • Protection class up to IP67 (mounted with O-ring)
  • Long life
  • Internal sealing
  • Return spring
  • Good price/performance ratio
