What's Your Angle?

Beyond measuring angles, Novotechnik’s R-Series of rotary position sensors can be programmed and reprogrammed for your application’s angle, CW/CCW direction and single or redundant output can be selected

R-Series sensors utilize the orientation of a magnetic field to determine measurement angle. An embedded microprocessor converts the magnetic orientation to an analog output that is repeatable to within 0.03% or 0.1° of measurement range – depending on model.

Key specifications include:

• Resolution: 12/14-bit
• Protection class: to IP67
• Measurement
